Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Gambar besar : Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Detail produk:

Tempat asal:	Cina
Nama merek:	chuangxin
Sertifikasi:	ce
Nomor model:	XD-D

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	negotation
Kemasan rincian:	Sedang mengemas
Waktu pengiriman:	30 hari
Menyediakan kemampuan:	10 Set Per Bulan

Kontak

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Deskripsi

Kapasitas Produksi:	2000sqm	Jenis:	Garis produksi panel dinding MGO
Penggunaan:	membuat panel dinding mgo	Pertunjukan:	kedap air, tahan api, tahan suara
Nomor model:	Desain sesuai permintaan Anda	Layanan purna jual:	Insinyur tersedia untuk melayani mesin di luar negeri
Menyoroti:	eps sandwich panel production line , roof panel roll forming machine

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

decorative magnesium oxide board production line capacity 2000 sheets / shift Mgo wall panel making machine

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift 0

Introduction of wall panel machine:

1. Metering System
After accurate weighing Fly ash, cement and sand, then being stirred with water into a slurry.
2. Forced mixing system
The slurry is transported by conveyor to the slurry compulsory mixer, and mixing with polystyrene particles evenly. Finally the slurry is poured into the mold.
3. Steam curing system.
The mould will be driven into curing room by the ferry cart for curing

Raw material proportion

Name	Ratio
Cement	50-70%
Flyash	20%
Sand	8%
Polystyrene	2%

wall panel making machine production line

No.	Name	Function	Size (mm)	Power(KW)	Quantity(set)
1	Slurry mixer	Mixing cement mortar of up and own materials	2300×820×820	3	2
2	Main mixer	Mixing middle materials	2800×1500×1300	18.5	2
3	Crusher	Crush and collection material after cutting	1960×880×1070	11	1
4	Duplex units feed in mould board	Automatic feed-in mould board on the main formed units, no need by manual, can reduce labor, improve work speed.	4800×3100×2800	1.5	1
5	Main formed units	It includes all of device of automatic feed-in cement mortar, fiber cloth, spreading, one-time forming and etc.	29000×1800×1500	11.5	1
6	oil brusher	It can adhibit the PVC paper on the mould board by automatic. (Or brush the oil on the mould board)	2700×1600×800	1.1	1
7	Automatic tracking cutting device	It can cut the product on production line when it’s wet, and it will not hurt the product and mould board, reduce the labor, low labor intensity .	4500×2000×1450	2.45	1
8	Hydraulic lifter of receiving board system	It can load the formed board on the form rack, reduce labor, reduce hurting the board when by manual, and improve automatic.	2700×3800×1700	9.6	1
9	PLC Control system	Control the production line automatic.	750×500×1800		1

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift 1
