Adjustable Thickness Board Making Machine for Magnesium Oxide Board / GRC Board

Adjustable Thickness Board Making Machine for Magnesium Oxide Board / GRC Board

GRC board  hollow sandwich wall panel making production line machine

Content Design (1)raw material supply

              (2)ingredients,mixing machine

              (3)molding equipment,auxiliary equipment

             (4)maintenance drying equipment

             (5)second maintenance area

             (6)drying,choosing,cutting,Edge banding machine,packing equipment

(1) raw materials supply

1.1The main raw material of magnesium oxide board :

   Magnesium oxide,Magnesium chloride, None-woven fabric, Glass

firber.,Sawdust ,Straws and Perlite

1.2 magnesium oxide warehouse

1.3magnesium chloride solution pool(suggestion uses two dissolve pool and matches mixing equipment)

1.4 pearlite storage(independent) different thickness of the plank use different degree of material.

1.5 sawdust storage(independent) different thickness of the plank uses different degree of material.

(2) second maintenance equipment,

2.1 On-the-shelf equipment

Maintenance workshop need  1000 square meters ,which are ventilated in summer, and insulated in winter.

2.2 off-the-shelf equipment

2.2.1 conveying out board and templates from bracket.

2.2.2 separation area, separated board with templated , board complete stacking by labor,and  template delivery into cleaning area. (need some flat cars)

2.3 auxiliary equipment

One boiler: choose big air blower,so that hot air get through maintenance workshop by pipe, make maintenance workshop reaches constant temperature, humidity. Temperature keep in 35-45 degrees , humidity is not less than 100%. Need air flow.

2.3.2 Clearing mold area:Two groups of four workers in charge of clear template, and send cleared template into the molding line equipment.

(3) choosing board, cutting, sealing side, packing,

3.1 cutting equipment: 1 set of cutting machine . Dust catcher and air blower.

3.2 Selecting board:  selecting and packing board by labor..

3.3 packing  ( counting and packing stacking board, this work need 4 person who will be divided into 2 groups).

Need 4 pcs bubble board pools :  3 meters * 3 meters

Need 1000 square meters bleachery ,which include drying rack (2.28 meters * 6 meters * 0.7 meters so that it can dry 50 pieces of board).

Magnesium board production quantity is based on the number of template.The equipment is the same.
